Chem 300 plus
Chem 300 plus
The Chem 300 PRO plus clinical chemistry analyzer features an extensive analysis menu combined with proven hardware and software to increase efficiency and reduce laboratory operating costs, plus the latest generation integrates QRCODE reagent reader and touch screen graphical interface.
The two reagent plate design is an innovative solution and thanks to its 30+30 positions in two different rotors gives to the lab the opportunity to work as it had two instruments.
Remote diagnostic control allows service staff to resolve errors quickly and efficiently without an on-site visit.
TECHNICAL DATA SHEET
| System Type | Fully Automatic, Random Access, STAT sample priority |
| Throughput | Up to 300 tests / hour |
| Analysis Methods | Endpoint (Bichromatic-Differantial-Sample blank), Kinetics, Fixed-Time, Turbidimetry |
| Calibration Curve | Linear, Non Linear, Cubic - Spline, Multi Point, Log - Logit |
| Sample Type | Serum, Plasma, Urine, CSF |
| Sample Positions | Removable tray, with 60 positions - Optional 20 tubes + 20 Hitachi cups = 40 positions |
| Sample Volume 2 - 300 ฮผl | 2 - 300 ฮผl |
| Sample Cuvettes | Tubes of 12 -13 mm, 5 - 7 ml / cups of 0.5-1.5 ml (require a metal adapter) - optional 20 tubes of 12 -16 mm / 20 cups (Hitachi type). |
| Sample Dilution | Yes - Automatic by software |
| Stat Samples | Yes |
| Sampling Technology | Capacitive Liquid Level Detection, needle shock sensor |
| Sample Barcode | Internal barcode reader |
| Reagent Positions | 2 Removable and Refrigerated Rack with 30 + 30 = 60 Reagent positions |
| Reagent Volume | 5 - 350 ฮผl |
| Reagent Bottles | 20 ml and 50 ml |
| Pipetting Technology | Capacitive Liquid Level Detection. Needle shock sensor |
| Reagent Storage | Cooling for both Reagent Rack with independent power supply |
| Reagent Barcode | Hand barcode reader included |
| Power Supply 1 | 00 - 240 Vac, 50 / 60 Hz, single phase with ground |
| Size / Weight | 93 x 74 x 60 cm (W x D x H), 75 kg |
| Reaction Cuvettes | 80 washable BIONEXยฎ cuvettes which allow approximately 20000 tests for a fully loaded rotor |
| Reaction Volume | 210 - 400 ฮผl |
| Reaction Time | Up to 11 min |
| Reaction Temperature | 38ยฐC ยฑ 0.1ยฐC |
| Optical Source | 1 halogen lamp (6 V, 10 W) with extended UV emission |
| Optical Range | 0 - 3 Abs Linearity ยฑ0.5% from 0.1 to 1.5 Abs |
| Optical Path | 6 mm |
| Wavelength | 8 interference filters of 340, 405, 505, 546, 578, 600, 650, 700 nm, 1 free position, 1 solid position for dark reading |
| Photo - Amplifier | Photoelectric detector, Signal amplifier, response range, 340 nm to 900 nm |
| Diluter Syringe | 368 ฮผl capacity, long-life syringe |
| Hydraulic System | 8 self-priming peristaltic pumps (life 800 hrs), 2 vacuum pumps Pinch Valve |
| Wash Station | Needles: 5 dispensating, 6 aspiration, 1 clearing (7 step washing sequence for each cuvette). Less than 3 l/hour water consumption. |
| Needle Wash | Internal and external with system solution |
| Run / Reaction Monitor | Operation status monitor on screen |
| Quality Control | Levey - Jennings Graphics - Westgard Algorithm |
| Operator Interface | Included touch screen 10โ- Intel HD Graphics SO windows - 4 GB DDR3 SDRAM Intel Pentium 1.6 GHz - SSD 64GB |
| Connections | Ethernet LAN port for LIS host communication, USB port for analyzer connection |
| Printer | External Printer |
| Environmental | 16 - 30 ยฐC, < 80% humidity |
